The
ViewEra V191BN 19”
TFT-LCD security monitors
produce fast response time of
5 ms plus wide viewing angle of 160°(H) /160°(V) ,
high contrast ratio of 800:1 (typ) and
brightness of 300 cd/m² (typ).
The V191BN delivers
resolution of 1280x1024 SXGA, uses 3D comb filter to get a sharp and vivid picture, supports BNC connector for security application and integrates two speakers of 2
watts. In addition, V191BN can do looping with one BNC Video IN and one BNC Video OUT. The base stand and slim frame
design makes the monitor look compact
and simple. The V191BN
provides high display quality, reliability
and space-saving. |
|
|
| Specification |
Model |
V191BN-B |
| Display |
Screen Size |
19 inch diagonal |
Panel Type |
Active Matrix, TFT LCD |
Active Screen Area |
376.32 (H) x 301.06 (V) mm |
| Pixel Pitch |
0.294(H) X 0.294(V) mm |
| Maximum Resolution |
1280(H) X 1024(V), SXGA |
| Resolution Support |
VGA, SVGA, XGA, SXGA |
| Brightness |
250 cd/m2 (Typ.) |
| Contrast Ratio |
'1000 : 1 (Typ.) |
| Response Time |
10 ms (Typ.) |
| Viewing Angle |
170°(H) / 160°(V) (Typ.) |
| Display Colors |
16.7M colors |
| Image Processing |
3D Comb Filter and De-Interlace |
| Vertical Frequency |
50~75Hz |
| Connectivity |
| VGA Input |
15 Pin D-Sub |
| Video Input |
1 CH BNC IN/OUT |
| Audio Input |
1 CH Composite (RCA) Audio (L/R) |
| Power |
DC In |
| Power |
| Power Supply |
AC Input: 100-240V~1.8A, 50-60HzDC
DC Output: 12V/5.0A |
| Power Consumption |
40 Watt (Max.) |
| Convenience |
| Front Control |
Power, Menu, Down, Up, Auto Image Adjustment |
| OSD Function |
Contrast, Brightness, Auto Image Adjust, H. Position, H. Phase, V. position,
H. Width, Sharpness, Color Temperature, Hue, Saturation, Flesh tone,OSD position, Language, Recall, Volume |
| Built-in Speakers |
3W x 2 |
| Adjustable Stand |
Tilt Adjustments |
| Safety & EMI |
FCC-B, CE |
| Wall Mountable |
VESA 75 bracket; Screw Spec: M4x8 |
| Accessory |
Power adapter, power cord, VGA cable, audio cable, User manual |
| Dimensions and Weight |
| Dimensions (Pack Size) |
19.1 (W) x 17.9 (H) x 6.1 (D) inch [485 (W) x 500 (H) x 155 (D) mm] |
| Dimensions (Set Size) |
16.7 (W) x 16.5 (H) x 6.9 (D) inch [425 (W) x 419 (H) x 174 (D) mm] |
| Dimensions (Without Stand) |
16.7 (W) x 14.75 (H) x 2 (D) [425 (W) x 375 (H) x 50 (D) mm] |
| Weight |
Net: 11 lbs (5 Kg) / Gross: 14.8 lbs (6.7 Kg) |
| Warranty |
| Manufacturer Warranty |
3 years |
|
|
| |
|
|
|
|
